Premium tapered roller bearings - ZVL Auto

Various range of tapered roller bearings

Needle Roller Bearing - ZVL Slovakia

These are bearings with or also without inner ring, may or may not have a sealing. These bearings have a lubricating groove and possibly also a hole on the outer ring.

Insert ball bearings and insert ball bearing housing units - ZVL Slovakia

Insert ball bearings are mainly used in simple arrangements, e. g. in agricultural machines, conveyer devices, food processing machines, construction machines, etc.

Double Row Angular Contact Ball Bearings - ZVL Slovakia

Double-row ball bearings with angular contact correspond with their construction and function to a pair of single row ball bearings with angular contact in „O“ - type configuration. They have rather deep raceways on both rings and may not be disassembled. In case of „E“ type construction, a  lubrication bore is made on one side.

Single row deep groove ball bearings - ZVL Slovakia

The single row deep groove ball bearings have relatively deep raceways on both rings without a filling slot and they are non-separable. By optimum size of balls and by their conformity to the raceways high load ratings are achieved.

Single row angular contact ball bearings - ZVL Slovakia

Single row four-point angular contact ball bearings - ZVL Slovakia

Single row four-point angular contact ball bearings are single row angular contact bearings The raceways of these bearings are designed to carry axial load in both directions.

Double row self-aligning ball bearings - ZVL Slovakia

Double row self-aligning ball bearings have spheral raceway on the outer ring. They can misalign and also the misalignment of seating is acceptable for them. Double row self-aligning ball bearings are produced with cylindrical or tapered bore and they are non-separable.

Single row cylindrical roller bearings - ZVL Slovakia

Single row cylindrical roller bearings are able to carry large radial load on a relatively small space. Some applications are able to carry also axial load in one or both directions. Raceways of the outer and inner rings together with the sheet profile of the cylindrical rollers in the shape of ZB allow optimal distribution of the contact pressure in the rolling space. This arrangement also allows advantageous formation of lubrication film between the contact parts of the bearing, optimal rolling, decrease of friction, growth of temperature and therefore lower stress of the junction in the arrangement.

Full complement cylindrical roller bearings - ZVL Slovakia

Due to their design with small construction height compared to the width, full complement cylindrical roller bearings are able to carry high loads while having small housing dimensions.

Double row spherical roller bearings with cylindrical and tapered bore - ZVL Slovakia

The spherical shape of the raceway in the outer ring enables the misalignment of the rings and ensures balanced distribution of load over the rolling elements even under the slightest shaft deflection, or even when the alignment of the bearing beds is not kept.

Single direction and double direction thrust ball bearings - ZVL Slovakia

Single direction and double direction thrust ball bearings can accommodate large axial load, however they must not be subjected to radial load. During operation these bearings must be constantly subjected to a specific axial load.

Cylindrical roller thrust bearings - ZVL Slovakia

Cylindrical roller thrust bearings are suitable for arrangements that are stiff and can carry high loads, they are resistant to shock loads.

Spherical roller thrust bearings - ZVL Slovakia

Spherical roller thrust bearings are able to carry high axial load. Because of their construction with spherical raceways and transmission of load at a certain angle they can carry radial load as well. They are dismountable which allows simpler installation of individual rings into the arrangement.

Spherical plain bearings - ZVL Slovakia

Spherical bearings type GE are radial plain bearings consisting of an outer ring and an inner ring made of bearing steel and with spherical sliding contact surface. These bearings are suitable for arrangements with heavy radial load at low misalignment and oscilation.

Furthermore the bearings can carry specific axial load in both directions.

Special bearings and special angular contact bearings - ZVL Slovakia

Special rolling bearings have non-standardized dimensions or design, eventually both. They are used for arrangements, where the designer because of various reasons cannot use standardized standard or modified bearings.

Series 500 PTFE Lined Butterfly Valves

Bidirectional bubble-tight concentric butterfly valves of Series 500 with PTFE sealing are offered for very clean manufacturig environments and are used in various industries.

Non-rising Stem Resilient Seated Gate Valve

Non-Rising Stem, bareshaft with ISO top flange prepared for Gearbox / Electric Actuator

Series 600 Concentric Butterfly Valves

ABO 600 series inter-flange soft-sealing centric industrial butterfly valves. Demountable with easy serviceability.

Series 900 Concentric Butterfly Valves

ABO 900 series inter-flange soft-sealing centric industrial butterfly valves. Demountable with easy service.

Arcusaflex - Highly flexible couplings - Reich Coupling Systems

Highly flexible rubber disc coupling for internal combustion engine drives.

ARCUSAFLEX-VSK - Highly-flexible U-joint couplings - Reich Coupling Systems

For use with combustion engines in conjunction with drive shafts for splitter gearboxes, torque converters, ship gearboxes, control gears and pump drives, for example in drives of construction equipment, excavators, cranes, marine propulsion, locomotives, pump installations and dump trucks.

Multi Cross Forte - Highly Flexible Coupling with Progressive Torsional Deflection Characteristic - Reich Coupling Systems

The MULTI CROSS FORTE (short form: MCF) is a highly flexible coupling with progressive torsional stiffness.

MULTI CROSS RILLO - Highly Flexible Tyre Coupling with Taper Bushes - Reich Coupling Systems

The MULTI CROSS RILLO (short form: MCR) are highly torsionally flexible tyre couplings with progressive torsional deflection characteristic.

iTOK - Highly flexible industrial couplings for flexibly mounted engines - Reich Coupling Systems

The highly flexible iTOK coupling has been specially designed for applications requiring extremely low torsional rigidity. Furthermore it is particularly well suited to the compensation of axial and radial displacements of flexibly mounted engines.

TOK Coupling System - Highly Flexible Coupling Shaft for Test Benches - Reich Coupling Systems

Test benches have a wide variety of applications in power transmission engineering. They are used to determine properties of test objects in research, development, manufacturing and quality assurance.

TOK DOCKING SYSTEM - Adaptive System for Engine Testing - Reich Coupling Systems

The aim of the system is to largely automate the test sample change during the testing of combustion engines.

ELBO - Flexible Pin-type Coupling - Reich Coupling Systems

ELBO couplings are flexible pin-type couplings and designed to compensate for axial, radial and angular shaft displacements.

MULTI MONT SELLA - Flexible Claw Coupling - Reich Coupling Systems

The torsionally flexible MULTI MONT SELLA couplings (short form: MMS) have been built in series since 1958.

MULTI MONT ASTRA - Flexible Claw Coupling with and without Taper Bushes - Reich Coupling Systems

The flexible MULTI MONT ASTRA coupling (short form: MMA) is a fail-safe claw coupling with flexible element for a torsionally flexible shaft connection.

REIBO - Flexible Pin-type Coupling - Reich Coupling Systems

REIBO couplings are torsionally flexible pin-type couplings which compensate for radial, axial and angular shaft displacements.

RCT - Torsionally Stiff Flange Couplings for Pump Drives - Reich Coupling Systems

With RCT couplings REICH offers an optimal drive solution for the connection of diesel engines to hydraulic pumps. Due to the torsionally stiff design of the RCT coupling, critical resonances can be shifted into the range above the operating speeds.

FLEXDUR – HighSpeed - Torsionally Rigid Coupling for Test Benches - Reich Coupling Systems

The FLEXDUR - HighSpeed (short form: FD-HS) All-metal couplings are developed and manufactured to the highest standards, especially for applications with higher speeds.

FLEXDUR - Torsionally rigid, flexible coupling - Reich Coupling Systems

The coupling uses bushed flexible disc packs of stainless spring steel as power transmitting elements. The special shape of the precision bushes results in a uniform tension distribution of the disc pack.

MULTI MONT SELLA – HighSpeed - Flexible claw coupling - Reich Coupling Systems

The torsionally flexible MULTI MONT SELLA couplings (short form: MMS) have been built in series since 1958.

TSA 031 Gearboxes

They consist of 9 standardized spur, bevel and bevel & spur gearboxes in four to six sizes. The TSA 031 gearbox line is designed using modular principle, what allows arranging various further versions with maintained axial distances and gears according to standardized row. Spur involute gearing is healical, corrected; bevel gear units are made with OERLIKON- ELOID-N gear design.

TSA E 031 electric gearboxes

They are created by connection of electric motor to individual types of TSA 031 using funnel shaped adaptor, shaft coupling dimensioned for engine power and they constitute one unit as a whole. Electric motor bearings are lubricated with fat filling. Various execution of slow-running shaft allows operation of gearboxes with electric motor.

Planetary gearboxes EP

Universal worm gearboxes UZP

Use of gearboxes is universal. They allow decrease of rotation frequency of prime mover, in case of deliveries with electric motor, decrease of rotation frequency of electric motor's rotor to required rotation frequency of prime mover’s shaft at coincident increase of torque at constant gear ratio.

TSP and TSR gearboxes

The design of spur and bevel & spur gearboxes is adapted to heavy working conditions and explosive environment (as in mining and power engineering industry) and the body moulds and housing cover, heat-treated shafts and gearing, bearings and labyrinth seals combined with rubber seals supplied by reputable companies meet that.

Gearboxes for truck concrete mixers PM, PMC and PMK

Gearboxes PM, PMC and PMK are designed for direct drum drive of truck concrete mixer with drum working volume 6 – 16 m3. Drum of concrete mixer body is in application assembled to gearbox driving flange that transmits torque from fluid motor to concrete mixer drum. Gearbox serves concurrently for mounting of front part of drum.

KCV gearboxes

KCV gearboxes are designed for drive of cooling tower fans.

Gearboxes of PSB type

Gearboxes of PSB type serve for drive of stationary concreting plants.

Winch DBP-160

Winch DBP-160 is a device that serves for lifting and lowering of upper platform of a railway carriage for transportation of cars.

Non-standard gearboxes

A large group consists of non-standard gearboxes projected and produced based on customers' specifications or customer drawings.

Single Screw Extruder Drives

The gear units of this DANA PIV series POSIREX for single-screw extruders are available with mounted or integrated thrust bearing, in helical and bevel helical version.

Twin Screw Extruder Drives

Highest torque values, optimum efficiency and maximum reliability are the hallmarks of our POSITWIN series of twin-shaft extruder drives.

Posired 2 Gears for Rubber

These gearboxes are based on the DANA POSIRED 2 series and are modified to drive rubber kneaders. The output shafts are adjusted according to customer requirements.

Injection Molding Drives

POSIRACK is a smooth running helical gearbox with a double-toothed rack. Case-hardened and ground gears ensure that high acceleration and deceleration torques are safely transmitted.

Industrial Series

This is a complete range of modular design planetary gearboxes, and combines high performance with low cost and compact size. The many years of commercial success achieved by DANA planetary gearboxes testify to their excellent quality and reliability, simple installation and limited maintenance.

S Series

The “S Series” is the optimum proposal for all applications requiring high torque with minimum dimensions, on fixed industrial equipment and also self-propelled machines. This planetary technology solution is preferable to solutions with traditional gear units as it offers an improvement of 40- 60% in terms of space and weight.

High Power Series

This powerful combination of planetary gear units and bevel helical gearboxes is the new solution provided by DANA Motion Systems for any high power industrial applications, such as: materials handling, mining, marine equipment, metal processing, pulp and paper, recycling industry. A comprehensive range of available accessories completes the product.

Industrial Slewing Drives

This range of DANA planetary gear units is specifically designed for to drive slewing rings in industrial applications.

Successfully employed since many years on tower cranes, shipboard and harbour cranes, wind generators and as steering drive on ship propulsion systems.

Mobile Slewing Drives

This range of DANA planetary gear units is specifically designed for to drive slewing rings in mobile applications.

Successfully employed since many years on mobile and rought terrain cranes, port equipment machines, truck cranes, utility and forestry vehcles.

Cattle Feeder Drives

Brevini’s range of cattle feed mixer drives are modular planetary gear units modified to meet the operating requirements of cattle feed mixers in agricultural industries.

EvoMax™

The Brevini EvoMax™ gearbox series is a further development of the POSIRED 2 series from Dana Motion Systems Deutschland. The development has incorporated over 90 years of application knowledge and customer feedback and the outcome is a series of highly reliable, efficient and economical products.

Posired 2 Series

The POSIRED 2 Series is a innovative product line based on a modular system. These superior gear units are produced with state of the art

design, material, and manufacturing technologies for maximum power and reliability within a cost-effective package.

Lifting/Hoisting Gearboxes

With this gearbox series, we provide the news 3 to 4 stage helical gearboxes suitable were a long center distance between input and output needed.

Long Travel Drives

Design and performance of the POSIRED D Series makes the product to a perfect solution for Crane Applications.

Posired TS

The POSIRED TS is suitable for applications where 2 counter rotating output shafts are required. It is available as helical gearbox or bevel helical gearbox.

Conveyor Drives

Based on the POSIRED 2 series is this Gearbox series developed for conveyor drives. The POSIRED Advanced has a higher mechanical efficiency and increased thermal performance and is perfect for application were no water is available for cooling.

PB-PLB Series

The PB and PLB Serie is a innovative product line based on the POSIRED 2 series. These superior gear units are produced with state of the art design, material, and manufacturing technologies for maximum power and reliability within a cost-effective package.

Compact Plano-Helical POSIPLAN

These Compact Plano-Helical Drives which are protected by a specific patent, feature a combination of planetary and helical gears that takes advantage of the strengths of each technology: compact size, high reliability and easy maintenance

Evolution Series Winches BWE

The New Winch Evolution series has been designed to have best-in-class performances to meet market needs. Feature high speed motors and device like the Torque Sensor, to improve safety and manouvrability. Suitable for Lifting of Personnel application and designed to work in severe condition, like cold weather and hursh and dust envinroment.

DW Series

Designed for light duty application, accessories and option available in standard configuration, compact and light to meet market requirements.

EGO Series

Designed for light and medium duty application, accessories and option available in standard configuration.

BWF Series

Compact solution featuring integrated axial piston motor. Used in light and medium duty application where small envelope is required. Different configuration available thanks to accessories and options available for this range.

BWT Series

Robust Design due to drum and frame made by nodular cast iron for heavy-duty application. Different Drum Length available to allow dfferent rope capacity according customer needs. Gerotor motor standard​, but also Orbital Motor and High Speed Piston Motor available​ upon request.

RCW Series

Modern design concept, featuring high strenght materials and tapered roller bearing to maximize the performances. Best in class torque density, ready to meet highest standard in marine and offshore. Perfect solution for mobile and stationary applications.

PWD Series

High load capacity and improved performances to meet market requirements. Wide range of product and configuration to fit different applications for mobile and stationary equipment.

SLW / SMW Series

Modular design, high performance design featuring high torque and load capacity. Designed for heavy duty application, able to fulfill the highest industry standards for mobile and stationary applications.

D Series

Helical gear units, their input and output shafts are parallel and they can be connected to machines from sides of housing, with torque arm or from output flange.

M/N Series

Foot/Flange-mounted, helical gear units with solid output shaft, Input and output shafts are parallel to each other.

K Series

Helical bevel gear units, their input and output shafts are perpendicular to each other. They can be mounted to machine from foot, output flange or with torquarm.

E Series

The worm gearboxes of the E series feature input and output shafts that are perpendicular to each other.Their worms are made of steel and gears are made of bronze.They can be mounted to the driven machine by the foot, flange or torque arm on the gearbox.

T Series

The TT Series gearboxes are helical-geared, two-staged, output-shaft-mounted units with a hollow output shaft and a monoblock housing. Housing material is GG20 cast iron and gears are made of high-quality case-hardened steel.

V Series

V series gear units are three stage, helical-geared hoist drum drive units. Input and output centre distances are as far apart as possible to allow the use of larger drums to achieve longer rope service life.

Pump Drives – BZ Series

We offers complete Pump Drive series according to different engine powers with multiple ports, flanges and coupling. Housing customization is also possible to overcome space constrains.

Solenoid Valve Drivers

Drivers to pilot directional control valves

Motors and Pumps Drivers

Drivers to pilot motors and pumps, standalone or in hydrostatic transmissions

Levelling Control Units

Control units to grant perfect levelling of platforms

Joysticks

Rugged body for mobile applications

Pre-programmed settings to fit wide range of our valves

Angle/tilt sensors

Rugged single and double axis inclinometer

Load Sensors

Load cells for mobile and industrial applications

Length Sensors

Dual redundant output available for functional safety applications

Programmable-customizable setting

Wide output range (anlalog and digital CANbus)

Insulated body

Electronic Control Units

Pre-programmed and programmable controllers

Anti-Vibration Systems

Characterized by excellent insulation properties and versatile applications, rubber seals are a reliable solution that provides strong protection against heat loss, the intrusion of unwanted fluids or gases, and more.
